MRCOOL 24K Downflow Two-Stage 230V 1-Phase 60Hz CuNi Coil Right w/Heater, GCHPD024TGTANDR

MRCOOL GeoCool 24K BTU Downflow Two-Stage CuNi Coil Right w/Heater (GCHPD024TGTANDR)

General Information

• Color: Grey
• Size: 25 Inches
• Dimensions: 25 3/4" W x 56" H x 32" D
• Voltage: 230 V
• Max Coverage: 1,000 Sq Ft
• Country of Manufacture: USA

Performance

• Cooling Capacity:
  • Ground Water: 23,000 - 29,000 BTU (Full Load)
  • Ground Loop: 21,900 - 27,000 BTU (Full Load)
• Heating Capacity:
  • Ground Water: 19,000 - 25,700 BTU (Full Load)
  • Ground Loop: 16,500 - 18,500 BTU (Full Load)
• EER Rating (Full Load):
  • Ground Water: 27.40
  • Ground Loop: 17.95
• EER Rating (Part Load):
  • Ground Water: 36.50
  • Ground Loop: 25.93

Features

• Quiet Operation
• Easy Service Access
• Insulated Sloped Stainless Steel Drain Pan
• Advanced Unit Control Board with Diagnostic LEDs
• Full-Featured Sinusoidal Eon Motor Control Technology
• Double O-Ring Water Connections
• Safety High and Low-Pressure Switches
• Desuperheaters for Enhanced Efficiency
• Optional Domestic Water Pre-Heating

Warranty

• 5-Year Limited Parts Warranty
• 10-Year Registered Parts Limited Warranty
• 10-Year Compressor Warranty
• Note: Warranties apply when registered and installed by a licensed professional.

Efficiency and Compliance

• Highest Energy Efficiency in Its Class
• Qualifies for Federal Tax Credit and Other Incentives
• Listings: ETL, Energy Star, AHRI

Installation Notes

• Blower Orientation: Downflow
• Ideal for Attic Installation
• Professional Installation Required

This product offers significant energy savings due to its two-stage compressor, which only uses the energy necessary to cool or heat your space. This design contributes to lower energy consumption and reduced monthly utility bills. The inclusion of a desuperheater further enhances its efficiency.
